SCM-6

Description

The SCM-6 is a 6 LED underwater marine light and provides your vessel with 24 watts of intense LED lighting. Choose from 5 different single colour options. The SCM-6’s low profile design allows for many mounting locations. The unique stainless steel housing compliments the look of any trailer or lift kept boat.

KEY FEATURES

• Proprietary clear-gel-filled design, injected through entire unit – eliminates condensation and/or water intrusion under stress
• Tough, polycarbonate lens
• Passivated stainless steel 316 material provides a durable corrosion resistant housing
• Transient surge and reverse polarity protection – dramatically prolongs unit life
• Thermal throttling technology – enables safe operation even out of water
• 3-Year Warranty

TECHNICAL INFORMATION

• Up to 2,400 lumens
• 120° beam angle
• 6 single colour LEDs
• 24 watts power draw
• 2.0 amps operating current draw @ 12 volts
• 10-30 volts input
• 183 mm x 61mm x 13mm
• IP68 fully submersible waterproof design

DATA SHEET LINK

• SCM-Series-4_6_10_Installation-Instructions_HR
• SCM-6-Series_Underwater-LED-Light-Datasheet_HR-1
• SCM-6_install-diagram-Rev-10-13-1-1

COLOURS AVAILABLE / PART NUMBER

Bimini Blue

• SCM-6-BB-20

Ultra Blue

• SCM-6-UB-20

Aqua Green

• SCM-6-AG-20

Cool Red

• SCM-6-CR-20

Great White

• SCM-6-GW-20
