SCM-DL Down Lights

$230.00 – $260.00

Upgrade your boat’s lighting with the SHADOW-CASTER® Marine LED Down Light SCM-DL a compact yet powerful overhead LED light designed for T-Tops, cabins, towers, and more. With a 51mm diameter, IP67 waterproof rating, and 300-lumen output, this energy-efficient marine LED light delivers wide-angle illumination. Enjoy seamless brightness and color control via a standard switch, with lighting options including single-color white, dual-colour white & blue, tri-colour white, blue & red, and full RGB. Choose between white or black finishes for a sleek, modern aesthetic.

Why Choose Shadow-Caster NZ?
Compact Marine LED Down Light – Ideal for cabins, T-Tops, baitwells & walkways
Soft Start Technology – Gradually brightens over 2 seconds for eye comfort
Power Toggle Control – Easily adjust brightness & colour from a standard switch
Multiple Colour Options – Choose from white, dual-colour white & blue, tri-colour white, blue & red, or full RGB
High Lumen Output 300lm – Provides bright, energy-efficient lighting
Durable & Waterproof IP67 Rated – Designed for marine environments
Sleek, Low-Profile Design – Available in white or black finishes
Shadow-NET® Interface – Included in colour-changing versions for advanced lighting control



Clear selection
SKU: scm-dl Category: Tags: , , , , , , , , , , , , , ,

Description

The SHADOW-CASTER marine LED down light SCM-DL is perfect for lighting overhead areas of the interior and exterior of your boat or yacht.

At 51mm overall diameter, its wide angle spread of light makes this perfect for lighting T-Tops, cabins, towers and more. Easily control the brightness and colour from a standard switch.

The SCM-DL series is available in 4 lighting colour output options: single colour white; 2 colour (blue and white); 3 colour (white, blue and red) as well as a full colour version. Choose from two colour finishes – white or black.

KEY FEATURES

  • Soft start technology ramps the brightness up gently over 2 seconds.
  • Power toggle feature to set brightness and change colour
  • True white LED for best colour performance
  • 120° viewing angle
  • High efficiency switch mode power supply
  • Waterproof low-profile aluminum housing

TECHNICAL INFORMATION

  • 300 lumen output
  • 120° beam angle
  • 3 watt power draw
  • 10-30 volts input
  • 250mA at 12 volts, 125mA at 24 volts
  • 6200 Kelvin cool white colour temperature
  • 51mm OD, 4mm mounting height
  • 31.75mm mounting hole
  • Durable glass lens
  • IP67 waterproof design
  • Colour change version includes Shadow-NET® interface for controlling colour (Part# SCM-DL-CC-WH/SCM-DL-CC-BK)

DATA SHEET LINK

COLOURS AVAILABLE / PART NUMBER

Full Colour – 12 colour lights (white or black housing)

  • SCM-DL-CC-WH
  • SCM-DL-CC-BK

White, Blue & Red – 3 colour lights

  • SCM-DL-WBR-WH (white housing)
  • SCM-DL-WBR-BK (black housing)

Blue/White – 2 colour lights (white housing)

  • SCM-DL-BW-WH

Great White – 1 colour light

  • SCM-DL-GW-WH (white housing)
  • SCM-DL-GW-BK (black housing)

Additional information

Colour

Great White, White/Blue/Red, Colour Changing, Blue/White
Housing Colour

Black, White
