SCM10-EXT-CC

Description

The SCM-10-EXT-CC extended colour 10 LED underwater marine light provides your vessel with 42 watts of intense LED lighting. Easily switch between 12 standard colours or use a Shadow-NET enabled controller to enjoy unlimited colours. The SCM-10-EXT-CC’s low profile design allows for many mounting locations. The unique stainless steel housing compliments the look of any trailer or lift kept boat.

KEY FEATURES

• Proprietary clear-gel-filled design, injected through entire unit – eliminates condensation and/or water intrusion under stress
• Tough, Polycarbonate lens
• Passivated Stainless Steel 316 material provides a durable corrosion resistant housing
• Transient surge and reverse polarity protection – dramatically prolongs unit life
• Thermal throttling technology – enables safe operation even out of water
• From simple on-off to full-feature lighting effects, unit is enabled for a host of control interfaces
• Select between 12 colours when using a switch or unlimited colours when using Shadow-NET® enabled products
• 3-Year Warranty

TECHNICAL INFORMATION

• Up to 3,750 lumens
• 120° beam angle
• 10 RGBW LEDs
• 42 watts power draw
• 3.5 amps operating current draw @ 12 volts
• 10-30 volts input
• 254 mm x 61mm x 13mm
• IP68 fully submersible waterproof design

DATA SHEET LINK

• SCM-10-EXT-CC-Underwater-LED-Lights_Datasheet-1
• SCM-10-EXT-CC-Operating-Instructions_HR

CONTROL OPTIONS

POWER TOGGLE CONTROL

• Quickly toggle power source to advance to next colour.

PUSH BUTTON CONTROL

• Connect to any push button controller. Ask about Shadow-Caster’s highest quality, marine-grade push button controllers, optimized to work seamlessly with your lighting requirements.
• Used with a single colour lights allows for any single colour on/off, fade blue to white, fade through all 12 colours and strobe current colour.

SHADOW-NET® CONTROL

• Full-feature control through your Multifunction Display (MFD) by adding the Shadow-NET® control module (SCM-MFD-LC-KIT) & app.
